(4) (4)
(1)
(2)
(3)
(1) odometer
(2) tripmeter A
(3) tripmeter B
(5)
(4)
(4) odometer/tripmeter
select button
(5) RESET button
(For TRX500FA)
23
Odometer/Tripmeter
Indicators & Displays
Instruments & Controls
The odometer/tripmeter display has two functions, odometer ( ) and
tripmeter.
The tripmeter has two sub modes, A ( ) and B ( ).
The odometer registers total distance traveled in miles while the ignition
switch is ON ( ).
The tripmeter shows mileage per trip while the ignition is ON ( ).
To change the display from tripmeter A or tripmeter B to odometer,
press and release the odometer/tripmeter select button ( ).
To reset the tripmeter to zero, press and hold the RESET button ( ) for
more than 2 seconds with the display in the tripmeter A or tripmeter B
mode.
4
5
1
23
05/06/08 10:48:38 31HN2650_032
