(2)
(1)
(3)
(3) utility box cover(1) utility box
(2) D-ring
FRONT FENDER
46
Utility Box
Instruments & Controls
Controls & Features
To open:
To close:
The utility box ( ) is located on the left side of the front fender. You
may store small, lightweight items in the box.
Lift the D-ring ( ) on the quick-release fastener. Turn it
counterclockwise until it releases. Open the utility box cover ( ).
Close the cover and turn the D-ring clockwise until it secures the cover.
1
2
3
05/06/08 10:51:53 31HN2650_055
