4.17 US gal (15.8 )
0.87 US gal (3.3
)
(2)(1)
(1) fuel gauge (2) segment RES
(1)
(2)
TRX500FA
TRX500FGA
TRX500FA TRX500FGA
29
Fuel Gauge
Indicators & Displays
Instruments & Controls
When segment RES ( ) flashes, you should refill the tank as soon as
possible. The amount of fuel remaining when the flashing starts is
approximately:
The fuel gauge liquid crystal display ( ) shows the approximate fuel
supply available. The fuel tank capacity is:
All segments will flash, when the fuel gauge function is fails. See your
Honda dealer.
1
2
05/06/08 10:49:36 31HN2650_038
