Honda TRX500FA 2006 User Manual

(3)
(1)
(2)
TRX500FGATRX500FA
(1)
(4)
(6)
(7)
(8)
(9)
(10)
(11)(12)(13)(14)
(5)
(6)
(12)
(14)(7)
(3)
(16)
(17)
(18)
(19)
(20)
(15)
(4)
(5)
(17) WP button (TRX500FGA)
(18) puls button (TRX500FGA)
(19) minus button (TRX500FGA)
(20) digital clock/hourmeter
(TRX500FGA)
(1) multi-function display
(2) RESET button (TRX500FA)
(3) odometer/tripmeter select button
(4) gear position indicator
(5) drive mode indicator
(6) speedometer
(7) fuel gauge
(8) hour select button (TRX500FA)
(9) minute select button (TRX500FA)
(10) adjust button (TRX500FA)
(11) hourmeter (TRX500FA)
(12) odometer/tripmeter
(13) digital clock (TRX500FA)
(14) oil change indicator
(15) digital clock/hourmeter
select button (TRX500FGA)
(16) GPS button (TRX500FGA)
19
Multi-function Display
Indicators & Displays
Instruments & Controls
The multi-function display ( ) includes the following functions:
The digital clock will reset if the battery is disconnected.
The tripmeter will reset if the battery is disconnected.
1
Speedometer
Odometer
Tripmeter
Drive mode indicator
Gear position indicator
Oil change indicator
Digital clock
Hourmeter
Fuel gauge
(TRX500FGA only)
