maximum weight capacity
front cargo rack weight limit
rear cargo rack weight limit
tongue and rear cargo weight
tongue weight
tow weight limit
485 lbs (220 kg)
66 lbs (30 kg)
133 lbs (60 kg)
133 lbs (60 kg)
=
=
=
=
=
30 lbs 14 kgf
(137 N) recommended
850 lbs 385 kgf
(3776 N)
maximum
85
Load Limits
Load Limits & Guidelines
Before Riding
Following are the load limits for your ATV:
There are limits to how much weight can be carried on your ATV and be
pulled in a trailer.
The following load limits apply to standard equipment only. Modifying
your ATV, using non-standard equipment, or riding on terrain that is not
flat and smooth could further reduce these limits.
(includes the weight of the rider, all cargo, and accessories.)
Tongue weight can be measured with an ordinary bathroom scale. Place
the scale under the tongue, using either a tongue jack or other support to
keep the trailer level.
(Combined weight on the trailer
tongue and on the rear cargo
rack)
(Weight on the trailer tongue)
(Combined weight of the trailer
and all cargo in the trailer)
The weight of added accessories will reduce the maximum cargo weight
you can carry.
05/06/08 10:58:00 31HN2650_094
