LEFT HANDLEBAR
(1) start button
(2) engine stop switch
(1)
(2)
START
OFF
RUN
36
Start Button
Engine Stop Switch
Controls & Features
Instruments & Controls
Starting Procedure,
If your ATV is stopped with the ignition switch ON ( ) and the
engine stop switch OFF ( ), the battery will discharge. Turn the
ignition switch OFF ( ) to prevent battery discharge.
The start button ( ) is used for starting the engine. Pushing the button in
starts the engine. See page .
When the start button is pushed, the starter motor will crank the engine.
The starter motor will not operate if the engine stop switch is in the OFF
( ) position when the start button is pushed.
The engine stop switch ( ) is used to stop the engine in an emergency.
To operate, slide the switch to either OFF ( ) position. The switch
must be in the RUN ( ) position to start the engine, and it should
normally remain in the RUN ( ) position even when the engine is
OFF.
1
97
2
05/06/08 10:50:34 31HN2650_045
