Honeywell Excel 800 LION User Manual

Excel 800 LION
7 EN1B-0375GE51 R0308
I/O Module Overview
Panel Bus
module
L ON W ORKS
Bus module
Description Inputs Outputs Manual controls LEDs
1)
CLIOP821A CLIOL821A Analog input module 8 – – –
CLIOP822A CLIOL822A Analog output module – 8 – 8 status LEDs
CLIOPR822
A
CLIOLR822A Analog output module – 8 8 Manual overrides 8 status LEDs
CLIOP823A CLIOL823A Binary input module 12 – – 12 status LEDs
CLIOP824A CLIOL824A Relay output module – 6
2)
– 6 status LEDs
CLIOPR824
A
CLIOLR824A Relay output module – 6
2)
6 Manual overrides 6 status LEDs
CLIOPR825
A
– Floating output module – 3 3 Manual overrides 3 pairs of status LEDs
1)
In addition to the power LED and service LED
2)
Changeover outputs
Table 3 Overview of I/O modules
Corresponding Terminal Sockets
I/O module
CLIO…
Socket Scope of delivery
…821
…822
XS821-22
1 terminal socket,
1 bridge connector
1 swivel label holder
…823 XS823
1 terminal socket,
1 bridge connector
1 swivel label holder
…824
…825
XS824-25
1 terminal socket,
1 bridge connector
1 swivel label holder
1 long cross connector
Table 4 I/O modules and corresponding terminal sockets
Note
In the following e.g., …822 is used to summarize all analog
output modules (Panel Bus/L ON W ORKS Bus, with/without
manual overrides)
