LYNX Touch Installation and Setup Guide
- 18 -
Mechanics of Programming
General Programming Information
When power cycling the control, remove AC power first and wait approximately 1 minute before
disconnecting battery.
Programming options are stored in non-removable, electrically erasable, nonvolatile EEROM memory. The
system can be programmed at any time, even at the installer's premises prior to the actual installation.
Simply apply power temporarily to the Control and then program the unit as desired.
The “Initiate Download” button is used to initiate remote programming using an IBM PC compatible
Personal Computer, and Compass Downloader and modem or via capable GSM or IP communications
modules. See the Remote Programming/Control (Downloading) section for additional information.
Programming
If the system is Armed or in Alarm, the Tools icon will not be functional. The system must first
be disarmed.
Enter Installer Programming Mode
SCREEN ACTION
Ready To Arm
5000-100-006-V1
Arm Away
Delay
Phone
More
Automation
Message
Zones
Arm Stay
72
10:18 AM June 8, 2010
1. At the Home Screen select “More”.
2. Select “Tools”. The touchscreen displays a keypad.
3. Enter the Installer Code 4112.
4. The System Programming Screen is displayed. Select
“Program” to display the following options:
Installer Code
Date Time
Zones
Keys
System Type
Communicator
Comm. Diagnostics
Reporter
Use the down T arrow to scroll to the next page of options.
Sounder
Default Config.
Reset Master Code
System Settings
Language*
Z-Wave
5. The system advances to the Programming screen of the
selected option.
* This programming field may not be available with the system
being installed.
To Next Page
