HP 16500C Service Manual

HP 16500C/16501A Logic Analysis System
The HP 16500C is the mainframe of the Logic Analysis System, and the HP 16501A is
the expansion frame. The HP 16500C/16501A is of a modular structure using plug-in
cards with a wide range of data acquisition and stimulus capabilities.
Features
Some of the main features of the HP 16500C/16501A are as follows:
• Modular mainframe with five card slots
• Expansion frame, which expands the total system card slots to ten
• Touchscreen user interface
• 545-Mbyte hard disk drive
• High-density 3.5-inch flexible disk drive
• Color monitor
• Intermodule triggering and time correlation of acquired data
• HP-IB, RS-232-C or Centronics interfaces for hardcopy output to a printer or
HP-IB, RS-232-C or LAN controller interface
• Target Control
Service Strategy
The service strategy for this instrument is the replacement of defective assemblies.
This service guide contains information for finding a defective assembly by testing
and servicing the HP 16500C/16501A.
This instrument can be returned to Hewlett-Packard for all service work, including
troubleshooting. Contact your nearest Hewlett-Packard Sales Office for more details.
ii
