Contents
1 General Information
Accessories 1-2
Specifications 1-3
Characteristics 1-3
Recommended Test Equipment 1-6
2 Preparing For Use
To inspect the logic analysis system 2-2
To apply power 2-3
To operate the user interface 2-3
To set the line voltage 2-4
To degauss the display 2-5
To clean the logic analysis system 2-5
To test the logic analysis system 2-5
To install modules 2-6
To connect the HP 16501A Expansion Frame 2-7
3 Testing Performance
To perform the power-up tests 3-3
To perform the self-tests 3-4
4 Calibrating and Adjusting
To prepare the instrument 4-3
To access the test patterns 4-4
To adjust geometry 4-5
To adjust focus, landing, and convergence 4-6
To adjust white balance 4-13
5 Troubleshooting
To use the flowcharts 5-2
To check the power-up self-tests 5-17
To run the self-tests 5-18
To check the video signals 5-21
To check the power supply LEDs 5-22
To check the power supply voltages 5-23
To test the flexible disk drive voltages 5-24
To test the hard disk drive voltages 5-26
