Specifications
The specifications are the performance standards against which the product is tested. There
are no specifications for the HP 16500C or the HP 16501A.
Characteristics
These characteristics are not specifications, but are included as additional information. The
following characteristics are typical for the HP 16500C/16501A system.
I/O Capabilities RS-232-C Configurations Protocols: XON/XOFF, Hardware; Data bits: 8; Stop bits: 1, 1
1/2, 2; Parity: none, odd, or even; Baud rates: 110, 300, 600, 1200, 2400, 4800, 9600, 19200.
HP-IB Interface Functions SH1, AH1, T5, TE0, L3, LE0, SR1, RL1, PP1, DC1, DT1, C0
and E2.
LAN IEEE 802.3 (ISO 8802-3) CSMA/CD, selectable between 10Base-T (Ethertwist) or
10Base2 (Thinlan).
Parallel Printer Port Standard LPT connector.
PS/2 Optional keyboard and mouse interface.
Target Interface Port Used with logic analyzer accessories specifically designed to
provide target system run control.
Hard Disk Drive Capacity 545 Mbyte unformatted; Formatted as a DOS disk drive with IDE Interface Bus.
Flexible Disk Drive Capacity 1.44 Mbyte formatted; DOS or LIF supported.
Programmability Instrument settings and operating modes, including automatic measurements, may be
remotely programmed via RS-232-C, HP-IB (IEEE-488), or LAN.
Hardcopy Output Printers Supported HP ThinkJet, HP QuietJet, HP LaserJet, HP PaintJet, HP Deskjet,
HP Deskjet C, Epson and Epson-compatible (for example, Epson FX-80) via RS-232-C,
HP-IB, or Parallel Printer (Centronics).
External Trigger
Rear Panel BNCs
Port-in
User selectable: TTL, ECL or user defined; Zin = 4 kΩ ; Maximum Vin = -6.0 V at
1.5 mA to +6 V at 1.6 mA (CAT I).
Port-out Selectable active high or active low; 3 V TTL-compatible output level,
high > 2 V into 50 Ω, low < 0.4 V into 50 Ω.
Intermodule Bus (IMB)
Characteristics
Run Control All modules can be armed by Group Run. Modules can run concurrently or
be armed in series. Each module can arm one or more modules.
Mixed Display Mode Any timing or oscilloscope waveform displays can be mixed.
State listings can be included with waveforms in the State/Timing Mixed Mode display.
General Information
Specifications
1–3
