112
Figure 100 Airflow through the chassis
(1) Left-side inlet air vents (2) Right-side outlet air vents
(3) Front panel
5800-24G-PoE+/5800-24G-PoE+TAA
Figure 101 shows the airflow design for the 5800-24G-PoE+ and 5800-24G-PoE+TAA switches. Cool air
flows in from the left side of the chassis, circulates through the chassis and the interface card, and
exhausts out the right side of the chassis.
