Appendix C Ports and LEDs
Ports
Console port
Every 5800 or 5820X switch has one console port.
Table 13 Console port specifications
Item S
Connector type
RJ-45
Compliant standard
EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a local or remote (through a pair of
modems) PC running terminal emulation program.
Management Ethernet port
The 5800-24G-SFP (1 slot), 5800-24G-SFP TAA (1 slot), 5800AF-48G, 5820AF-24XG,
5820X-24XG-SFP+, and 5820X-24XG-SFP+ TAA switches have one management Ethernet port. You can
connect this port to a PC or management station for loading and debugging software or remote
management.
Table 14 Management Ethernet port specifications
Item S
Connector type RJ-45
Connector quantity 1
Port transmission rate 10/100/1000 Mbps, half/full duplex
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
USB port
Every 5800 or 5820X switch has one OHC-compliant USB2.0 port that can upload and download data
at a rate up to 12 Mbps. You can use this USB port to access the file system on the Flash of the switch, for
example, to upload or download application and configuration files.
