Removal and Replacement Procedures
b. Move to the front of the rack and loosen the thumbscrews securing the server to the
rack (1).
c. Grasp the front panel thumbscrews, and extend the server from the rack. The cables
remain clamped in the cable tray. The rail release latches engage automatically.
d. Press in and hold the rail release latches (2).
e. Extend the server completely out of the rack (3), and set it on a flat, level surface.
Figure 2-3: Removing the server from the rack
Reverse these procedures to replace the server into the rack.
Server Access Panel
WARNING:
To reduce the risk of personal injury from hot surfaces, allow the internal
system components to cool before touching them.
CAUTION: Before removing the server access panel, be sure that the server is powered
down and that the power cord is disconnected from the server or the electrical outlet.
CAUTION: Electrostatic discharge can damage electronic components. Be sure you are
properly grounded before beginning any installation procedure.
HP ProLiant DL360 Generation 3 Server Maintenance and Service Guide 2-7
