LEDs, Switches, and Jumpers
System Maintenance Switch (SW2)
The system maintenance switch (SW2) is an eight-position switch used for system
maintenance. Refer to the labels attached to the inside of the server access panel for the
proper system configuration switch settings. The following table shows the shipping
configuration of SW2.
Table 5-4: System Maintenance Switch (SW2) Settings
Position Function Default Description
S1 iLO service
override
Off Off = No function
On = Override iLO security enabled
S2 Configuration lock Off Off = System configuration can be changed
On = System configuration is locked
S3 Reserved On Reserved
S4 Floppy disable Off Off = Disable floppy boot
On = Override RBSU setting and enable floppy boot
S5 Password override Off Off = Honor RBSU password setting
On = Override RBSU setting and override password
prompts
S6 Reset configuration Off Off = No function
On = ROM reads system configuration as invalid,
reset configuration
S7 Reserved Off Reserved
S8 Reserved Off Reserved
Note: “On” activates the function.
Hot-Plug Redundant Power Supply/PCI Switch (SW1) Settings
The hot-plug redundant power supply/PCI switch (SW1) is a four-position switch used for
system maintenance. Refer to the labels attached to the inside of the server access panel for
the proper switch settings. Table 5-5 shows the shipping configuration of SW1.
Table 5-5: Hot-Plug Redundant Power Supply/PCI Install Switch (SW1) Settings
Position Function Default Description
S1 Reserved Off Reserved
S2 Reserved On Reserved
S3 Reserved Off Reserved
S4 Identify PCI slot or redundant
power supply support
Off Off = Normal (PCI slot 2 supported)
On = Hot-plug redundant power supply
installed
5-6 HP ProLiant DL360 Generation 3 Server Maintenance and Service Guide
