Table 2-3 Boards and their descriptions (continued)
Item Description
(4) Fingerprint sensor board
*
RFID module
*
RF asset module
*
WLAN modules
Intel Wireless-AC 9560 802.11ac 2 × 2 Wi-Fi + Bluetooth® 5.0 (vPro)
Intel Wireless-AC 9560 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 (non-vPro)
Intel Wi-Fi 6 AX200 + Bluetooth 5.0 (802.11ax, 2 × 2, vPro, supporting gigabit le transfer speeds)
Intel Wi-Fi 6 AX200 + Bluetooth 5.0 (802.11ax, 2 × 2, non-vPro, supporting gigabit le transfer speeds)
Realtek RTL8822BE 802.11 ac 2 × 2 Wi-Fi + BT 4.2 Combo Adapter (MU-MIMO supported)
*
not illustrated
Mass storage devices
Table 2-4 Mass storage devices and their descriptions
Description
Optical drive
DVD Blu-ray-writer
DVD-ROM drive
Hard drive, 2.5 inch
2 TB, 5400 rpm, 7.0 mm
1 TB, 7200 rpm, 9.5 mm
500 GB, 7200 rpm, 7.0 mm
500 GB, 5400 rpm, 7.0 mm
500 GB, 7200 rpm hard drive, 7.0 mm, self-encrypting (SED)
500 GB, 5400 rpm hard drive, 7.0 mm, FIPS
Solid-state drive, 2.5 inch, SATA-3, TLC
512 GB, FIPS 140-2
512 GB, self-encrypting (SED)
512 GB
256 GB, FIPS 140-2
256 GB, self-encrypting (SED)
256 GB
M.2 solid-state drive (NVMe, PCIe)
2 TB, TLC
12 Chapter 2 Illustrated parts catalog
