Adjustable height stand
To remove the stand:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 23).
2. Remove the rear port cover, if it is installed. For instructions, see Removing the rear port cover
on page 23.
3. Press the release latch under the stand (1).
4. Lift the stand up (2), and then pull the stand hooks out of the computer (3)).
Access panel
The computer has one main rear access panel that allows access to internal components.
To remove the access panel:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 23).
2. Remove the rear port cover (see Removing the rear port cover on page 23).
3. Remove the stand (see Stands on page 24).
4. Pull up the notches of the access panel, and then lift the access panel o the computer.
To replace the access panel, reverse the removal procedures.
Access panel 25
