97
Task Command
Display the login information of NP_Ports.
display fc nport [ interface interface-type
interface-number ]
Display the nodes on downlink interfaces and their
mapped uplink interfaces.
display npv login [ vsan vsan-id ] [ interface
interface-type interface-number ]
display npv login [ vsan vsan-id ] count
Display the traffic mapping information.
display npv traffic-map [ vsan vsan-id ] [ interface
interface-type interface-number ]
Display status information. display npv status [ vsan vsan-id ]
NPV configuration examples
Network requirements
As shown in Figure 28, configure the edge switch (Switch A) as an NPV switch to expand the network.
Figure 28 Network diagram
Configuration procedure
1. Configure Switch A:
# Configure the switch to operate in advanced mode. (Skip this step if the switch is operating in
advanced mode.)
<SwitchA> system-view
[SwitchA] system-working-mode AdvancedBridge
Do you want to change the system working mode? [Y/N]:y
The system working mode is changed, please save the configuration and reboot the
system to make it effective.
# Save the configuration.
[SwitchA] save
The current configuration will be written to the device. Are you sure? [Y/N]:y
Please input the file name(*.cfg)[flash:/startup.cfg]
(To leave the existing filename unchanged, press the enter key):
Validating file. Please wait...
