Introducing the E3800 Switches
Fronts of the Switches
These products also support optional network connectivity:
Management Ports
Console Port
This port is used to connect a console to the switch by using the serial cable
supplied with the switch. This connection is described under “9. (Optional)
Connect a Management console” on page 2-18 in chapter 2, “Installing the
Switch.” The console can be a PC or workstation running a VT-100 terminal
emulator, or a VT-100 terminal.
Table 1-2. Optional Network Connectivity, Speeds and Technologies
Transceiver Form-Factor and Connector
1
Speed Technology Cabling SFP ("mini-GBIC")
Connector
SFP+
Connector
100 Mbps
100-FX Fiber (multimode) LC
100-BX Fiber (single mode) LC
1 Gbps
1000-T Copper (twisted-pair) RJ-45
1000-SX Fiber (multimode) LC
1000-LX Fiber (multimode or single mode) LC
1000-LH Fiber (single mode) LC
1000-BX Fiber (single mode) LC
10 Gbps
10-Gig
Direct Attach
Copper (twinaxial)
Not
Applicable
10-Gig SR Fiber (multimode)
LC
10-Gig LRM Fiber (multimode) LC
10-Gig LR Fiber (single mode) LC
10-Gig ER Fiber (single mode) LC
1
For supported transceivers, visit www.hp.com/networking/support.
– In the first textbox, type J4858 (for 100-Mb and Gigabit information), or J8436 (for 10-Gigabit information).
– Select any of the products that display in the dropdown list.
– Select Product support information. Then click on Manuals and find the Transceiver Support Matrix.
For technical details of cabling and technologies see "Cabling and Technology Information" in the appendices.
