2-1
2
Installing the Switch
The HP E3800 switches come with an accessory kit that includes the brackets
for mounting the switch in a standard 19-inch telco rack, in an equipment
cabinet, and with rubber feet that can be attached so the switch can be
securely located on a horizontal surface. The brackets are designed to allow
mounting the switch in a variety of locations and orientations. For other
mounting options contact your local HP authorized network reseller or HP
representative. This chapter shows how to install the switch.
Caution If the switch is to be shipped in a rack, it can be mounted and shipped in any
four post rack using HP X410 E-Series 1U Universal Rack Mounting Kit
(J9583A). Optionally, it can also be mounted in an HP 10K rack using the HP
1U RK MT SWITCH 10K ALL rail kit, part number 356578-B21 and shelf kit
AB469A, HP rx 16/26 Factory Rackmount Shelf Kit (both kits must be used,
otherwise you will void the warranty).
Included Parts
The HP E3800 switches have the following components shipped with them:
■ HP Switch Quick Setup Guide
■ Switch Safety and Regulatory sheet
■ Warranty notice
■ General Safety and Regulatory booklet
■ Console cable
■ Accessory kit
(5069-5705) for Non-PoE+ E3800 switches (5066-0651) for PoE+ E3800 switches
two mounting brackets two mounting brackets
eight 8-mm M4 screws to attach the
mounting brackets to the switch
eight 8-mm M4 screws to attach the
mounting brackets to the switch
four 5/8-inch number 12-24 screws to attach
the switch to a rack
four 5/8-inch number 12-24 screws to
attach the switch to a rack
four rubber feet four rubber feet
