To do… Use the command… Remarks
Display RMON prialarm
configuration information
display rmon prialarm
[ entry-number ] [ | { begin |
exclude | include }
regular-expression ]
Available in any view
Display RMON events
configuration information
display rmon event
[ entry-number ] [ | { begin |
exclude | include }
regular-expression ]
Available in any view
Display log information for the
specified or all event entries.
display rmon eventlog
[ entry-number ] [ | { begin |
exclude | include }
regular-expression ]
Available in any view
Ethernet statistics group configuration example
Network requirements
As shown in Figure 38, Agent is connected to a configuration terminal through its console port and to
Server through Ethernet cables.
Configure the RMON Ethernet statistics table to gather incoming packet statistics for GigabitEthernet
1/0/1, so the administrator can view the incoming traffic status of the interface at any time.
Figure 38 Network diagram for RMON
Configuration procedure
# Configure RMON to gather statistics for interface Ethernet 1/0/1.
<Sysname> system-view
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] rmon statistics 1 owner user1
The system gathers incoming packet statistics for GigabitEthernet 1/0/1. To view the statistics:
• Execute the display command.
<Sysname> display rmon statistics Ethernet 1/0/1
EtherStatsEntry 1 owned by user1-rmon is VALID.
Interface : Ethernet1/0/1<ifIndex.3>
etherStatsOctets : 21657 , etherStatsPkts : 307
etherStatsBroadcastPkts : 56 , etherStatsMulticastPkts : 34
etherStatsUndersizePkts : 0 , etherStatsOversizePkts : 0
etherStatsFragments : 0 , etherStatsJabbers : 0
100
