To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as HTTP,
and enter test type view
type http Required
Configure the IP address of the
HTTP server as the destination
address of HTTP request packets
destination ip ip-address
Required
By default, no destination IP
address is configured.
Configure the source IP address of
request packets
source ip ip-address
Optional
By default, no source IP address is
specified.
The source IP address must be the
IP address of a local interface. The
local interface must be up;
otherwise, no probe packets can
be sent out.
Configure the operation type operation { get | post }
Optional
By default, the operation type for
the HTTP is get, which means
obtaining data from the HTTP
server.
Configure the website that an HTTP
test visits
url url Required
Configure the HTTP version used in
HTTP tests
http-version v1.0
Optional
By default, HTTP 1.0 is used.
Configure optional parameters
See “Configuring optional
parameters for an NQA test
group”
Optional
NOTE:
The TCP port must be port 80 on the HTTP server for NQA HTTP tests.
Configuring UDP jitter tests
NOTE:
Do not perform NQA UDP jitter tests on known ports, ports from 1 to 1023. Otherwise, UDP jitter tests
might fail or the corresponding services of this port might be unavailable.
Real-time services such as voice and video have high requirements on delay jitters. UDP jitter tests of an
NQA test group obtain uni/bi-directional delay jitters. The test results help you verify whether a network
can carry real-time services.
A UDP jitter test performs the following procedure:
1. The source sends packets to the destination port at regular intervals.
17
