To do… Use the command… Remarks
Configure the interval the NQA
client must wait for a response from
the server before it regards the
response is timed out
probe packet-timeout
packet-timeout
Optional
3000 milliseconds by default.
Configure the source IP address for
UDP jitter packets
source ip ip-address
Optional
By default, no source IP address is
specified.
The source IP address must be the
IP address of a local interface. The
local interface must be up;
otherwise, no probe packets can
be sent out.
Configure optional parameters
See “Configuring optional
parameters for an NQA test
group”
Optional
NOTE:
The probe count command specifies the number of probe operations during one UDP jitter test. The probe
packet-number command specifies the number of probe packets sent in each UDP jitter probe operation.
Configuring SNMP tests
SNMP tests of an NQA test group are used to test the time the NQA client takes to send an SNMP packet
to the SNMP agent and receive a response.
Configuration prerequisites
Before you start SNMP tests, enable the SNMP agent function on the device that serves as an SNMP
agent. For more information abut SNMP agent configuration, see the chapter “SNMP configuration.”
Configuring SNMP tests
Follow these steps to configure SNMP tests:
To do… Use the command… Remarks
Enter system view system-view —
Enter NQA test group view
nqa entry admin-name
operation-tag
—
Configure the test type as SNMP,
and enter test type view
type snmp Required
Configure the destination address
of SNMP packets
destination ip ip-address
Required
By default, no destination IP
address is configured.
Specify the source port of SNMP
packets
source port port-number
Optional
By default, no source port number
is specified.
19
