To do… Use the command… Remarks
Configure a reaction entry for
monitoring packet round-trip time
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element rtt
threshold-type { accumulate
accumulate-occurrences | average }
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the packet loss in each
test (only supported in UDP jitter
and voice tests)
reaction item-number checked-element
packet-loss threshold-type accumulate
accumulate-occurrences [ action-type { none |
trap-only } ]
Configure a reaction entry for
monitoring one-way delay jitter
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element { jitter-ds
| jitter-sd } threshold-type { accumulate
accumulate-occurrences | average }
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the one-way delay
(only supported in UDP jitter and
voice tests)
reaction item-number checked-element { owd-ds
| owd-sd } threshold-value upper-threshold
lower-threshold
Configure a reaction entry for
monitoring the ICPIF value (only
supported in voice tests)
reaction item-number checked-element icpif
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
Configure a reaction entry for
monitoring the MOS value (only
supported in voice tests)
reaction item-number checked-element mos
threshold-value upper-threshold lower-threshold
[ action-type { none | trap-only } ]
NOTE:
• NQA DNS tests do not support the action of sending trap messages. The action to be tri
gg
ered in DNS
tests can only be the default one, none.
• Only the test-complete keyword is supported for the reaction trap command in a voice test.
Configuring the NQA statistics collection function
NQA groups tests completed in a time period for a test group, and calculates the test result statistics. The
statistics form a statistics group. To view information about the statistics groups, use the display nqa
statistics command. To set the interval for collecting statistics, use the statistics interval command.
When the number of statistics groups kept reaches the upper limit and a new statistics group is to be
saved, the earliest statistics group is deleted. To set the maximum number of statistics groups that can be
kept, use the statistics max-group command.
A statistics group is formed after the last test is completed within the specified interval. When its hold time
expires, the statistics group is deleted. To set the hold time of statistics groups for a test group, use the
statistics hold-time command.
Follow these steps to configure the NQA statistics collection function:
To do… Use the command… Remarks
Enter system view system-view —
