Hardware options installation 37
Air baffle configuration for all other DIMMs
1. Remove the two air flow covers from the top of the air baffle.
2. Install the air flow covers on each end of the air baffle.
Installing a DIMM
CAUTION: To avoid damage to the hard drives, memory, and other system components, the
air baffle, drive blanks, and access panel must be installed when the server is powered up.
1. Power down the server blade (on page 13).
2. Remove the server blade (on page 14).
