Hardware options installation 45
19. (Optional) Install the BBWC battery pack on the air baffle. If excess BBWC cable exists, loop and
store the extra cable in the available space on the air baffle.
20. Install the access panel (on page 15).
21. Install the server blade ("Installing a server blade" on page 20).
HP Trusted Platform Module option
Use these instructions to install and enable a TPM on a supported server blade. This procedure includes
three sections:
1. Installing the Trusted Platform Module board (on page 46).
2. Retaining the recovery key/password (on page 47).
3. Enabling the Trusted Platform Module (on page 47).
Enabling the TPM requires accessing the ROM-Based Setup Utility (RBSU) ("HP ROM-Based Setup
Utility" on page 60). For more information about RBSU, see the HP website
(http://www.hp.com/support/smartstart/documentation
).
TPM installation requires the use of drive encryption technology, such as the Microsoft® Windows®
BitLocker™ Drive Encryption feature. For more information on BitLocker™, see the Microsoft website
(http://www.microsoft.com
).
CAUTION: Always observe the guidelines in this document. Failure to follow these guidelines
can cause hardware damage or halt data access.
When installing or replacing a TPM, observe the following guidelines:
• Do not remove an installed TPM. Once installed, the TPM becomes a permanent part of the system
board.
• When installing or replacing hardware, HP service providers cannot enable the TPM or the
encryption technology. For security reasons, only the customer can enable these features.
• When returning a system board for service replacement, do not remove the TPM from the system
board. When requested, HP Service provides a TPM with the spare system board.
