6
Specifications
Table 6-1: Server Specifications
Feature Units
Dimensions
Height 17.5 cm (6.88 in)
Depth 69.2 cm (27.25 in)
Width 46.3 cm (19.0 in)
Weight
30.8 kg, minimum (68 lb, minimum)
44.5 kg, maximum (98 lb, maximum)
High-line voltage requirements
Rated input voltage 180 V to 264 V
Rated input frequency 47 Hz to 63 Hz
Rated input current 6 A
Low-line voltage requirements
Rated input voltage 90 V to 132 V
Rate input frequency 47 Hz to 63 Hz
Rated input current 12 A
Power supply output power
Rated steady-state power 800 W
Maximum peak power 800 W
Temperature range
Operating
10° to 35°C (50° to 95°F)
Non-operating
-30° to 60°C (-20° to 140°F)
Relative humidity (non-condensing)
Operating 20% to 80%
Non-operating 5% to 90%
Maximum wet bulb temperature
38.7°C (101.7°F)
Heat dissipation 3900 BTU/Hr
HP ProLiant DL585 Server Maintenance and Service Guide 6-1
