Illustrated Parts Catalog

System Components Spare Parts List

Table 1-2: System Components Spare Parts List

Item Description Assembly

Number

Spare Part Number Customer Self

Repair (Yes/No)

Media Storage Devices

1 Diskette drive, 12.7 mm, universal

media (optional)

263394-001 267132-001 Yes

2a CD-ROM drive, 24X, universal media 222837-001 228508-001 Yes

2b DVD-ROM drive, 8X, universal media

(optional)*

168003-935/901 268795-001 Yes

Boards

4 SCSI backplane 010879-001 231128-001 Yes

5 Diagnostic display board and lightpipe 012134-001 356784-001 Yes

6 Pass-through board 010873-001 249106-001 Yes

7 System board 011977-001/002 356782-001 No

8a Processor Memory Board

(PC2100/PC2700)**

011974-001/002 356783-001 Yes

8b Processor Memory Board (PC3200)** 012567-001 378476-001 Yes

9a Processor, 1.6 GHz 359126-001 359769-001 Yes

9b Processor, 1.8 GHz 359126-002 359770-001 Yes

9c Processor, 2.2 GHz 359126-003 359771-001 Yes

9d Processor, 2.4 GHz 351926-104 371755-001 Yes

9e Processor, 2.6 GHz 382281-006 382043-001 Yes

Reserved

* Not shown

** Mixing processor speeds or cache sizes is not supported.

continued

HP ProLiant DL585 Server Maintenance and Service Guide 1-5
