Huawei FusionServer Pro 1288H V5 User Manual

(channels 1 and 2, or channels 1, 2, and 3). The DIMMs installed
must be identical in size and organization.
▪ For a multi-processor conguration, each processor must have a
valid memory mirroring conguration.
– Memory scrubbing mode
▪ Comply with the general installation guidelines.
2.4.5 Memory Installation Positions
A 1288H V5 supports a maximum of 24 DDR4 DIMMs. To maximize the
performance, balance the total memory capacity between the installed processors
and load the channels similarly whenever possible.
NO TICE
At least one DDR4 DIMM must be installed in the memory slots corresponding to
CPU 1.
Figure 2-15 Memory slots
FusionServer Pro 1288H V5 Server
User Guide 2 Hardware Description
Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 23

Huawei FusionServer Pro 1288H V5 Specifications

General

Processor	Intel Xeon Scalable processors
Memory	Up to 3 TB
Memory Slots	24 DDR4 DIMM slots
Storage	Supports up to 10 x 2.5-inch SAS/SATA/SSD drives or 4 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, 60
Network	2 x GE + 2 x 10GE ports
Power Supply	1+1 redundant, hot-swappable PSUs
Form Factor	1U rack
