Huawei FusionServer Pro 1288H V5 User Manual

Port Type Indicator Description
10GE electrical
port
Transmission rate
indicator
● O: The data transmission rate is
10/100 Mbit/s.
● Steady green: The data transmission
rate is 10 Gbit/s.
● Steady yellow: The data
transmission rate is 1 Gbit/s.
Connection status
indicator/Data
transmission
status indicator
● O: No data is being transmitted or
the network port is not connected.
● Blinking green: Data is being
transmitted.
● Steady green: The network port is
properly connected.
25GE optical port Data transmission
rate indicator for
an optical port
● O: The network port is not
connected.
● Steady green: The data transmission
rate is 25 Gbit/s.
● Steady yellow: The data
transmission rate is 10 Gbit/s.
Connection status
indicator/Data
transmission
status indicator
● O: The network port is not
connected.
● Blinking green: Data is being
transmitted.
● Steady green: The network port is
properly connected.
56G IB optical
port
Connection status
indicator
● O: No physical link is set up.
● Blinking green: The physical link is
abnormal.
● Steady green: The physical link is
normal.
Data transmission
status indicator
● O: No logical link is set up.
● Blinking yellow: Data is being
transmitted.
● Steady yellow: The logical link is
normal but no data is being
transmitted.
2.7 I/O Expansion
FusionServer Pro 1288H V5 Server
User Guide 2 Hardware Description
Issue 13 (2020-06-05) Copyright © Huawei Technologies Co., Ltd. 31

Huawei FusionServer Pro 1288H V5 Specifications

General

Processor	Intel Xeon Scalable processors
Memory	Up to 3 TB
Memory Slots	24 DDR4 DIMM slots
Storage	Supports up to 10 x 2.5-inch SAS/SATA/SSD drives or 4 x 3.5-inch SAS/SATA drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, 60
Network	2 x GE + 2 x 10GE ports
Power Supply	1+1 redundant, hot-swappable PSUs
Form Factor	1U rack
