Huawei S6700 Series Hardware Description

l Transmit power: 0 dBm to 4.0 dBm
l Receiver sensitivity: ≤ -28.0 dBm
l Overload optical power: -8.0 dBm
l Extinction ratio: ≥ 8.2 dB
GE Copper Module
Table 7-6 lists the attributes of a GE copper module.
Table 7-6 Attributes of a GE copper module
Model Transmission
Distance (km)
Rate Connector
Type
Standard
SFP-1000BaseT
≤ 0.1
Supporting rates of
10 Mbit/s, 100
Mbit/s, and 1000
Mbit/s when used
on a GE optical
port, and
supporting only the
rate of 1000 Mbit/s
when used on a
10GE optical port
NOTE
The optical port
must support
copper modules.
RJ45 1000Base-T
7.4.2 SFP+ Modules
Appearance
Figure 7-5 shows the appearance of an SFP+ optical module.
S6700 Series Ethernet Switches
Hardware Description 7 Pluggable Modules for Interfaces
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
99
