Table 2-19 Attributes of a console port
Attribute Description
Connector type RJ45
Standards
compliance
RS-232
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Baud rate 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, or 115200 bit/s
Default value: 9600 bit/s
ETH Management Port
You can connect a switch to a configuration terminal or network management workstation
through the ETH management port to configure the switch locally or remotely. The port must
use a network cable. You can choose to download the software package through the ETH
management port in the BootLoad menu. File transfer through the ETH management port is
faster than transfer through the console port. For details on how to use the ETH management
port, see the Configuration Guide - Basic Configurations. Table 2-20 describes the attributes
of an ETH management port.
Table 2-20 Attributes of an ETH management port
Attribute Description
Connector type RJ45
Standards
compliance
IEEE802.3
Working mode 10/100 Mbit/s auto-sensing
Full duplex
Maximum
transmission
distance
100 m
USB Port
The USB port can have a USB flash drive connected to upgrade the switch, or transfer
configuration files or other files. The USB flash drive used on an S6720-EI switch must support
USB 1.1 or USB 2.0 and be compatible with the Linux operating system.
2.5.5 Power Supply Configuration
S6700 Series Ethernet Switches
Hardware Description
2 Chassis
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
37
