9 Fan module slot
NOTE
Applicable fan module:
FAN-060B-B fan module
10 Power module slot 2
NOTE
l 350 W DC power module
l 600 W AC power module
11 Power module slot 1
NOTE
l 350 W DC power module
l 600 W AC power module
- -
2.5.3
Indicator Description
Table 2-13 is a quick reference table for indicators of S6720-EI switches.
Table 2-13 S6720-EI indicator quick reference table
Switch Model Indicator Description
S6720-30C-
EI-24S-AC
Symbols and meanings of indicators on the S6720-54C-EI-48S-AC are
the same as those on the S6720-30C-EI-24S-AC. S6720-30C-EI-24S-
AC is used as an example here.
S6720-54C-
EI-48S-AC
NOTE
Hold down this button for 6 seconds and release it to start the web initial login mode. Either of the following
situations will occur:
l If the switch has no configuration file, the system attempts to enter the web initial login mode. In this
mode, the status of mode indicators is as follows:
l If the system enters the web initial login mode successfully, all mode indicators turn green and
stay on for a maximum of 10 minutes.
l If the system fails to enter the initial login mode, all mode indicators fast blink for 10 seconds
and then restore to the default states.
l If the switch has a configuration file, the system cannot enter the web initial login mode. In this case,
all mode indicators fast blink for 10 seconds, and then return to the default states.
