Huawei S6700 Series Hardware Description

Display Mode Color Description
Stack Green and
yellow
l Off: Port indicators do not show the
stack ID of the switch.
l If both indicators are steady on, the
switch is not a master switch:
– If the indicator of a port is steady on,
the number of this port is the stack
ID of the switch.
– If the first nine port indicators of the
switch are steady on, the stack ID of
the switch is 0.
l If both indicators are blinking, the
switch is a master switch:
– If the indicator of a port is blinking,
the number of this port is the stack
ID of the switch.
– If the first nine port indicators of the
switch are blinking, the stack ID of
the switch is 0.
2.4.4 Port Description
10GE SFP+ Ethernet Optical Port
A 10GE SFP+ Ethernet optical port supports auto-sensing to 1000 Mbit/s. It receives and sends
service data at 1 Gbit/s or 10 Gbit/s. Table 2-6 describes the attributes of a 10GE SFP+ Ethernet
optical port.
Table 2-6 Attributes of a 10GE SFP+ Ethernet optical port
Attribute Description
Connector type LC/PC
Optical port
attributes
Depend on the optical module used (see 7.4.1 SFP/eSFP Modules and
7.4.2 SFP+ Modules)
Standards
compliance
IEEE802.3ae
Working mode GE/10GE auto-sensing
Full duplex
S6700 Series Ethernet Switches
Hardware Description
2 Chassis
Issue 12 (2015-07-31) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
19
