6.8 Copper Cable
Types of Copper Cables
Table 6-10 shows the types of copper cables.
Table 6-10 Types of copper cables
Model Length Electrical
attribute
Bend Radius Connector
Type
SFP-10G-
CU1M
1 m Passive 25 mm SFP+
SFP-10G-
CU3M
3 m Passive 25 mm SFP+
SFP-10G-
CU5M
5 m Passive 30 mm SFP+
SFP-10G-
AC10M
10 m Active 25 mm SFP+
QSFP-40G-
CU1M
1 m Passive 55 mm QSFP+
QSFP-40G-
CU3M
3 m Passive 60.5 mm QSFP+
QSFP-40G-
CU5M
5 m Passive 67 mm QSFP+
QSFP-4SFP10
G-CU1M
1 m Passive 25 mm QSFP+ to
4*SFP+
QSFP-4SFP10
G-CU3M
3 m Passive 25 mm QSFP+ to
4*SFP+
QSFP-4SFP10
G-CU5M
5 m Passive 50 mm QSFP+ to
4*SFP+
NOTICE
The two ends of a copper cable must be covered by electrostatic discharge (ESD) caps.
When used for data transmission between service ports, copper cables can only connect switches
of the same subseries, and cannot be used between switches of different subseries or between
Huawei and non-Huawei switches.
