Figure 5-36 4G Smart Dongle: SDongleB-06
Figure 5-37 Installing anti-theft components for the Smart Dongle
5.9 (Optional) Installing an Antenna
Procedure
Step 1 Remove the watertight cap from the ANT port.
Step 2 Install the washer to the ANT port on the device.
Step 3 Install the WLAN antenna.
Ensure that the WLAN antenna is installed securely.
SUN2000-(8K, 10K)-LC0 Series
User Manual 5 Electrical Connections
Issue 01 (2023-09-15) Copyright © Huawei Digital Power Technologies Co., Ltd. 72
