TECHNICAL DATA
Technical data
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/
EC. Reported sound power level for the machine has been measured with the original cutting attachment that gives the
highest level. The difference between guaranteed and measured sound power is that the guaranteed sound power also
includes dispersion in the measurement result and the variations between different machines of the same model
according to Directive 2000/14/EC.
Note 2: Reported data for equivalent sound pressure level for the machine has a typical statistical dispersion (standard
de
viation) of 2.5
dB(A).
Note 3: Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1.5 m/s
2
.
Technical data 531RS 541RS 541RST
Engine
Cylinder displacement, cm
3
33,6 41,5 41,5
Cylinder bore, mm 36 40 40
Stroke, mm 33 33 33
Idle speed, rpm 2500 2500 2500
Recommended max. speed, rpm 12000 12000 12000
Speed of output shaft, rpm 8570 8570 8570
Max. engine output, acc. to ISO 8893, kW/ rpm 1,2/7000 1,6/7000 1,6/7000
Ignition system
Spark plug NGK BPMR 7A NGK BPMR 7A NGK BPMR 7A
Electrode gap, mm 0,6-0,7 0,6-0,7 0,6-0,7
Fuel and lubrication system
Fuel tank capacity, litre 0,94 0,94 0,94
Weight
Weight without fuel, cutting attachment and guard, kg 7,2 7,2 7,2
Noise emissions
(see note 1)
Sound power level, measured dB(A) 107 107 107
Sound power level, guaranteed L
WA
dB(A) 108 109 109
Noise levels
(see note 2)
Equivalent sound pressure level at the operator’s ear,
measured according to EN ISO 11806 and ISO 22868,
dB(A):
Equipped with trimmer head (original) 90 94 94
Equipped with grass blade (original) 89 95 95
Equipped with saw blade (original)
Vibration levels
(see note 3)
Equivalent vibration levels (a
hv,eq
) at handles, measured
according to EN ISO 11806 and ISO 22867, m/s
2
Equipped with trimmer head (original), left/right 2,8/3,0 3,1/2,8 5,6/5,1
Equipped with grass blade (original), left/right 4,2/4,0 4,5/5,0 7,1/6,3
Equipped with saw blade (original), left/right
H1159210-30, GBESPT Page 28 Friday, October 6, 2017 1:00 PM

Husqvarna 236R Specifications

General

Weight	7.2 kg
Fuel Tank Volume	0.5 l
Sound Power Level, Guaranteed (LWA)	107 dB(A)
Power output	0.8 kW
Engine Type	2-stroke
Fuel Tank Capacity	0.5 l
Shaft Type	Straight
Sound Power Level	107 dB(A)
