8
8-17
• To increase the inflation pressure:
Switch on the compressor. To check
the current tire inflation pressure
setting, briefly switch off the
compressor.
• To reduce the tire inflation pressure:
Press the button (9) on the
compressor.
Information
The pressure gauge may show higher than
actual reading when the compressor is
running. To get an accurate tire reading, the
compressor needs to be turned off.
CAUTION
If the tire inflation pressure is not
maintained, drive the vehicle a second
time, refer to step 9.
Then repeat steps 10 to 13.
Use of the TMK may be ineffectual for tire
damage larger than about 0.16 in. (4 mm).
Contact an authorized HYUNDAI dealer if
the tire cannot be made roadworthy with
the Tire Mobility Kit.
WARNING
The tire inflation pressure must be at least
32 psi (220 kPa). If it is not, do not
continue driving.
Call for road side service or towing.
CAUTION
Tire pressure sensor (if equipped with
TPMS)
The sealant on the tire pressure sensor
and wheel should be removed when you
replace the tire with a new one and
inspect the tire pressure sensors. Have
this done at an authorized HYUNDAI
dealer.
Information
When reinstalling the repaired or replaced tire
and wheel on the vehicle, tighten the wheel
lug nut to 79-94 lbf·ft (11-13 kgf·m).
How to Adjust Tire Pressure
B8002510
1. Park your vehicle in a safe location.
2. Connect the filling hose (3) of the
compressor directly to the tire valve.
3. Plug the compressor power cord into
the vehicle power outlet.
4. Adjust the tire inflation pressure to the
recommended tire inflation.
With the vehicle on ( indicator on),
proceed as follows.
• To increase the inflation pressure:
Switch on the compressor. To check
the current tire inflation pressure
setting, briefly switch off the
compressor.
• To reduce the tire inflation pressure:
Press the button (9) on the
compressor.
3
Hyundai_CE_en_US.book Page 17
