IBM BladeCenter HS22 User Manual

Chapter 6. Solving problems
Use these instructions to resolve any problems you may encounter while installing
the blade server.
If you install the blade server in the BladeCenter unit and the blade server does
not start, perform the following actions:
v Make sure that the BladeCenter unit is correctly connected to a power source.
v Reseat the blade server in the BladeCenter unit (see “Installing the blade server
in a BladeCenter unit” on page 51).
v If the power-on LED is flashing slowly, turn on the blade server (see “Turning
on the blade server” on page 18).
v If you have just added a new optional device or component, make sure that it is
correctly installed and compatible with the blade server and its components. If
the device or component is not compatible, remove it from the blade server,
reinstall the blade server in the BladeCenter unit, and then restart the blade
server.
If the blade server does not start after you have performed the preceding actions,
see the Problem Determination and Service Guide for your blade server on the IBM
Documentation CD.
Diagnostic tools overview
Use this overview to locate specific diagnostic tools to diagnose and solve
hardware-related problems.
The following tools are available to help you diagnose and solve hardware-related
problems:
v POST codes, error messages, and error logs
The POST error codes indicate the detection of a problem. See the Problem
Determination and Service Guide for more information.
v Troubleshooting tables
These tables list problem symptoms and actions to correct the problems. See the
Problem Determination and Service Guide for your blade server.
v Light path diagnostics
Use light path diagnostics LEDs on the system board to diagnose system errors.
If the system-error LED on the system LED panel on the front or rear of the
BladeCenter unit is lit, one or more error LEDs on the BladeCenter unit
components also might be lit. These LEDs help identify the cause of the
problem. Blade server error LEDs are described in the Problem Determination and
Service Guide for your blade server.
v Dynamic System Analysis (DSA) Installable and Portable Edition diagnostic
program
DSA tests the major components of the BladeCenter unit, including the
management modules, I/O modules, removable-media drives, and the blade
servers, while the operating system is running. DSA can be plugged into an
existing IBM Director environment or installed without IBM Director present.
For documentation and download information for DSA, see
© Copyright IBM Corp. 2010 71

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
