Icom IC-905 User Manual

2
SCOPE OPERATION (ADVANCED)
2-4
SCOPE SET screen
Waveform Type (Default: Fill)
Selects the outline waveform display for the FFT
scope screen�
• Fill: Displays only the waveform, in color�
• Fill+Line: Displays both the waveform and the
outline, in color�
Waveform Color (Current)
(Default: (R) 172 (G) 191 (B) 191)
Sets the waveform color for the currently received
signals�
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to adjust the level from 0
to 255�
L The color is displayed in the box above the RGB scale�
Waveform Color (Line)
(Default: (R) 56 (G) 24 (B) 0)
Sets the waveform outline color for the currently
received signals�
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to adjust the level from 0
to 255�
L The color is displayed in the box above the RGB scale�
Waveform Color (Max Hold)
(Default: (R) 45 (G) 86 (B) 115)
Sets the waveform color for the received signals
maximum level�
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to adjust the level from 0
to 255�
L The color is displayed in the box above the RGB scale�
Waterfall Display (Default: ON)
Turns the Waterfall display ON or OFF for the normal
scope or Mini scope screen�
L On the Expanded scope screen, the Waterfall is always
displayed�
• OFF: Turns OFF the Waterfall display�
• ON: Turns ON the Waterfall display�
Waterfall Speed (Default: Mid)
Selects the Waterfall speed�
• Slow: Sets the Waterfall speed to Slow�
• Mid: Sets the Waterfall speed to Mid�
• Fast: Sets the Waterfall speed to Fast�
Waterfall Size (Expand Screen) (Default: Mid)
Selects the Waterfall height in the Expand scope
screen�
• Small: The same height as the Normal scope
screen, only the FFT scope expands�
• Mid: The Waterfall height expands at the same
ratio as the FFT scope�
• Large: Only the Waterfall height expands�
Waterfall Peak Color Level (Default: Grid 8)
Selects the signal level that the Waterfall displays a
peak color�
Higher signal levels are Red, Yellow, Green, Light-
blue, Blue, and Black, in that order�
• Select between Grid 1 and Grid 8�
Waterfall Marker Auto-hide (Default: ON)
Turns the Waterfall Marker Auto-hide function ON or
OFF�
• OFF: The marker in the Waterfall zone stays ON�
• ON: The marker in the Waterfall zone is hidden 2
seconds after it stops in place�

Icom IC-905 Specifications

General

LAN Port	Yes
Power Supply	13.8 V DC
Modes	FM, SSB, CW, AM
Display	4.3-inch color TFT touch screen
GPS	Yes
USB Port	Yes
Antenna Connector	N-type
