Icom IC-T70A User Manual

29
New2001New2001
MEMORY/CALL CHANNELS
6
New2001
■ General description
The IC-T70A/T70E has 300 memory channels, and 2 call
channels. Memory channels include 50 scan edge memory
channels
(25 pairs) to store often-used frequencies.
Also, 26 memory banks, A to Z, are available in each band for
storing groups of frequencies, etc. Up to 100 channels can be
assigned to a bank.
D Memory channel contents
The following information can be programmed into memory
channels:
•Operatingfrequency
(p. 20)
•Operatingmode(p. 21)
•Duplexdirection(+DUP or –DUP) with a frequency offset
(p. 26)
•ReverseduplexfunctionON/OFF(p. 26)
•Subaudibletoneencoder(p. 24), tone squelch or DTCS
squelch ON/OFF
(p. 70)
•Subaudible tone frequency (p. 53), tone squelch fre-
quency or DTCS code with polarity
(p. 53)
•Scanskipsetting(p. 46)
•Memorybank(p. 32)
•Memoryname(p. 34)
•Tuningstep(p. 19)
•Outputpower(p. 22)
NOTE: Memory data can be erased by static electricity, electric transients, etc.
In addition, it can be erased by malfunction and during repairs. Therefore, we recommend that memory data be written down or
be saved to a PC using the CS-T70
c l o n i n g s o f t w a r e .
■ Selecting a call channel
q Push [V/M/C] to select the call channel mode.
•Pushing[V/M/C] toggles between the VFO mode, the memory
channel mode, call channel mode and weather channel mode*.
* Only the U.S.A. version transceiver.
w Rotate [DIAL] to select a desired call channel.
•“C0”and“C1”areselectable.
[DIAL]
VHF band call channel
UHF band call channel

Icom IC-T70A Specifications

General

Operating frequency	144 – 148, 440 – 450 MHz
Display type	LCD
Backlight display	Yes
Antenna connector type	FA-S270C
Number of antenna connectors	1
Battery type	BP-265
Product color	Black
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30 mm
Width	58 mm
Height	111 mm
Weight	380 g
