Icom IC-T70A User Manual

31
6
MEMORY/CALL CHANNELS
New2001 New2001
q Push [V/M/C] to select the VFO mode.
w Set a desired frequency:
➥ Push [BAND] to select a desired band.
➥ Rotate [DIAL] to set a desired frequency.
➥ Push the keypad keys directly to set a desired fre-
quency. In this case, setting the band and frequency
using [BAND] and [DIAL] are not required.
➥ Set other data (e.g. frequency offset, duplex direction,
tone squelch, etc.), if desired.
e Push and hold [S.MW](V/M/C) for 1 sec. to enter the select
memory write mode.
•1shortand1longbeepsounds.
•The“ ” icon and memory channel number blink.
r Rotate [DIAL] to select a desired channel.
•Callchannels(C0,C1),VFOandscanedgechannels(0A/0b
to 24A/24b), as well as regular memory channels, can be pro-
grammed in this way.
t Push and hold [S.MW](V/M/C) for 1 sec. to program.
•3beepssound.
•Memorychannelnumberautomaticallyincreaseswhencontinu-
ing to push [S.MW](V/M/C) for 1 sec. after programming.
NOTE: Push [H/M/L] to cancel the program and exit the
select memory write mode before memory programming is
finished.
[DIAL]
The VFO mode Enter the select memory write mode.
to select channel 11.Rotate
Push and hold for 1 sec.
Return to the VFO mode.
Push and hold for 1 sec. to program.
[EXAMPLE]: Programming 145.440 MHz into memory channel 11 (a blank channel).
Channel 11
■ Memory channel programming

Icom IC-T70A Specifications

General

Operating frequency	144 – 148, 440 – 450 MHz
Display type	LCD
Backlight display	Yes
Antenna connector type	FA-S270C
Number of antenna connectors	1
Battery type	BP-265
Product color	Black
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30 mm
Width	58 mm
Height	111 mm
Weight	380 g
