Icom IC-T70A User Manual

43
7
SCAN OPERATION
New2001 New2001
■ Scan edges programming
Scan edges can be programmed in the same manner as
memory channels. Scan edges are programmed into scan
edge memory channels, 0A/0b to 24A/24b.
q Push [V/M/C] to select the VFO mode.
w Set a desired frequency:
➥ Push [BAND] to select a desired band.
➥ Rotate [DIAL] to set a desired frequency.
➥ Program different frequencies in “✱A” and “✱b.”
➥ Set other data
(e.g. frequency offset, duplex direction, tone
squelch, etc.), if desired.
e Push and hold [S.MW](V/M/C) for 1 sec. to enter the select
memory write mode.
•1shortand1longbeepsounds.
•The“ ” icon and memory channel number blink.
r Rotate [DIAL] to select a desired programmed scan edge
channel from 0A to 24A.
t Push and hold [S.MW](V/M/C) for 1 sec. to program.
•3beepssound.
•Theotherscanedgechannel“b,”0bto24b,isautomaticallyse-
lected when continuing to push [S.MW](V/M/C) after program-
ming.
y To program a frequency for the other pair of scan edges,
0b to 24b, repeat steps w and t.
•Ifthesamefrequencyisprogrammedintoapairofscanedges,
programmed scan will not function.
[DIAL]
The VFO mode
Enter
the select memory write mode.
to selectRotate
Push and hold
for 1 sec. “3A.”
“3A” is selected.
Return to the VFO mode.
Push and hold
for 1 sec.
[EXAMPLE]: Programming 145.300 MHz into scan edges 3A.

Icom IC-T70A Specifications

General

Operating frequency	144 – 148, 440 – 450 MHz
Display type	LCD
Backlight display	Yes
Antenna connector type	FA-S270C
Number of antenna connectors	1
Battery type	BP-265
Product color	Black
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30 mm
Width	58 mm
Height	111 mm
Weight	380 g
