Icom IC-T70A User Manual

New2001
81
13
OPTIONS
New2001
D VOX-related settings
The VOX gain, the VOX delay, and the VOX time-out timer
can be set in the Set mode.
q Connect an optional headset and plug adapter cable to the
transceiver, and then turn the power ON.
w Push [SET] to enter the Set mode.
e Rotate [DIAL] to select the VOX gain (VOX LV), the VOX
delay (VOX.dLy), or the VOX time-out timer (VOX.tot) item.
r Rotate [VOL] to select a desired option.
t Push [V/M/C] to exit the Set mode.
The VOX function does not activate transmission while in
the Set mode.
• VOX gain
The VOX gain level can be adjusted between 1 (minimum)
and 10 (maximum), or turned OFF. Higher values make the
VOX function more sensitive to your voice. (default: 5)
➥ While speaking into the headset microphone, adjust the
VOX gain until “VOX” continuously appears on the LCD.
✔ CONVENIENT!
While transmitting using the VOX function, you can adjust the
VOX gain simply by rotating [DIAL].
• VOX delay
Sets the VOX delay to between 0.5 and 3.0 seconds (in 0.5
sec. steps). The VOX delay is the amount of time the transmit-
ter stays ON after you stop speaking. (default: 0.5)
If “VOX” is intermittent, be sure the VOX delay is set long
enough to allow normal pauses in speech, but keep the
VOX ON until you finish speaking.
• VOX time-out timer
Sets the VOX time-out timer to between 1, 2, 3, 4, 5, 10 and
15 minutes to prevent accidental prolonged transmission for
the VOX function.
To turn the function OFF, select “OFF.” (default: 3)
The VOX time-out timer must be set shorter than the time-
out timer, otherwise this timer will not be activated.

Icom IC-T70A Specifications

General

Operating frequency	144 – 148, 440 – 450 MHz
Display type	LCD
Backlight display	Yes
Antenna connector type	FA-S270C
Number of antenna connectors	1
Battery type	BP-265
Product color	Black
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30 mm
Width	58 mm
Height	111 mm
Weight	380 g
