Ihse K480-288 User Manual

Draco tera
234 2020-02-26
Matrix
Keyboard Command
Description
<'Hot Key'>, <o>
Open OSD
<‘Hot Key‘>, <m>, <o>
Open OSD of the master matrix in a cascaded
environment
<‘Hot Key‘>, <s>, <o>
Open OSD of the sub matrix in a cascaded
environment
<'Hot Key'>,
<Backspace>
Close the current connection of the own
console
<'Hot Key'>, <p>
Switch back to the previous connected source
(computer, CPU) with a KVM connection
<'Hot Key'>, <1> ...
<16>, <Enter>
(<Space> or <Left
Shift> + <Enter>)
Switch to a source (computer, CPU) stored in
the Favorite List with a KVM connection (video
only or Private-Mode connection)
<'Hot Key'>, <F1> ...
<F16>
Execute a predefined macro (macro 1-16)
<'Hot Key'>,
<Left Shift> + <F17> ...
<F32>
Execute a predefined macro (macro 17-32)
<'Hot Key'>, <c>, <new
'Hot Key'-Code>,
<Enter>
Change the 'Hot Key' according to the
predefined 'Hot Key' table
<'Hot Key'>, <c>, <0>,
<new 'Hot Key' key >,
<Enter>
Define freely selectable 'Hot Key'
<'Hot Key'>, <f>, <new
'Hot Key'-Code>,
<Enter>
Change the 'Hot Key' for direct OSD access
according to the predefined 'Hot Key' table
<'Hot Key'>, <f>, <0>,
<new 'Hot Key' key>,
<Enter>
Define freely selectable 'Hot Key' for direct
OSD access
<'Hot Key'>, <Num 0>
Switch the USB-HID signal to the user’s display
(CON Unit with keyboard and mouse)
<'Hot Key'>, <Num 1>
Switching of the USB-HID signals to display #1
<'Hot Key'>, <Num 2>
Switching of the USB-HID signals to display #2
<'Hot Key'>, <Num 3>
Switching of the USB-HID signals to display #3
<'Hot Key'>, <Num 4>
Switching of the USB-HID signals to display #4
