Ihse K480-288 User Manual

Draco tera
84 2020-02-26
Field
Selection
Description
Auto Save
activated
Save the current configuration of the matrix
in the flash memory periodically.
Note: During the save operation, the matrix
will not be operational. Saving takes place
every 600 seconds, as long as changes of
the configuration or switching operations
have been executed in the meantime.
deactivated
Function not active (default)
Enable
COM Echo
activated
Send all switching commands performed in
the matrix as an echo via serial interface.
Note: This function should be enabled
when using a media control via serial
interface.
deactivated
Function not active (default)
Enable LAN
Echo
activated
Send all switching commands performed in
the matrix as an echo via LAN connection.
Note: This function should be enabled
when using a media control via LAN
connection or when using stacking with two
ore more matrices.
deactivated
Function not active (default)
Enable
Redundancy
activated
Automatically switch to the second link of a
connected redundant CON Unit when
losing the primary link of a CPU Unit
(default)
Note: This function will have to be activated
for both matrices in a fully redundant setup
deactivated
Function not active
Synchronize
activated
Synchronize the sub matrix to the switch
status of the master matrix.
deactivated
Function not active (default)
Echo Only
activated
Synchronize the matrix according to the
echo of a second matrix.
Note: This is a bidirectional synchronization
where both matrices have to be configured
as Synchronize with the Master IP of the
respective other matrix.
deactivated
Function not active (default)
Master IP
Address
Numerical
value
Set the network address of the master
matrix (default value: 000.000.000.000)
