Inovance ISMG1-17D15CD-A3 FA Series User Manual

1 Product Information
1
- 7 -
Servo Motor Model
Rated
Output
(kW)
Rated
Torque
(N·m)
Instan.
Max.
Torque
(N·m)
Rated
Current
(Arms)
Instan.
Max.
Current
(Arms)
Rated
Speed
(min
-1
)
Max.
Speed
(min
-1
)
Torque
Para.
(Nm/
Arms)
Rotor
Inertia
(kg·m
2
10
-3
)
Vol-
tage
(V)
ISMG2-42D15CD-U***FA
ISMG2-42D15CD-A3**FA
36.1 230 492.2 74.7 166.5 1500 1800 3.03 36.8 380
ISMG2-57D20CD-U***FA
ISMG2-57D20CD-A3**FA
48.2 230 495 87.8 207.8 2000 2400 2.06 36.8 380
Note
The standard motor model is -U231*. If you require other models, contact Inovance.
Instan. = Instantaneous
1.3 Servo System Conguration
Table 1-3 Servo motor and drive matching conguration
Rated
Speed
(RPM)
Max.
Speed
(RPM)
Capa-
city
(kW)
Servo Motor Model
ISMG□-□□□□□□□
Cooling
Method
Motor
Frame
Servo Drive Model
IS650P□□□□□□□
Drive
Size
Drive
SN
(H01-
02)
Motor
SN
(H00-
00)
Three-phase 380
VAC
1500 1800 7.9
G1
ISMG1-95C15CD-U***FA
ISMG1-95C15CD-A3**FA
Force
venti-
lation
200
IS650PT025IUX-B G 20001 14020
2000 2400 10.5
ISMG1-12D20CD-U***FA
ISMG1-12D20CD-A3**FA
IS650PT032IUX-B G 20002 14020
1500 1800 11.8
ISMG1-14D15CD-U***FA
ISMG1-14D15CD-A3**FA
IS650PT037IUX G 20003 14020
1500 1800 14.5
ISMG1-17D15CD-U***FA
ISMG1-17D15CD-A3**FA
IS650PT045IUX G 20004 14020
1500 1800 18.1
ISMG1-22D15CD-U***FA
ISMG1-22D15CD-A3**FA
IS650PT060IUX H 20005 14020
1500 1800 23.6
ISMG1-30D15CD-U***FA
ISMG1-30D15CD-A3**FA
IS650PT112IUX I 20008 14020
1500 1800 36.1
G2
ISMG2-42D15CD-U***FA
ISMG2-42D15CD-A3**FA
266
IS650PT112IUX I 20008 14020
1500 1800 48.2
ISMG2-57D20CD-U***FA
ISMG2-57D20CD-A3**FA
IS650PT112IUX I 20008 14020
1.4 Specications of Regenerative Resistor
Table 1-4 Recommendation of regenerative resistor
Drive Model
Regenerative Resistor Specications
Resistance (Ω) Power (kW)
IS650PT025IUX-B 43 1.3
IS650PT032IUX-B 32 1.3
IS650PT037IUX 25 1.3
IS650PT045IUX 20 2
