6 Parameter Table
6
- 89 -
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H12-67
Acceleration/deceleration time
of 16th speed reference
0: No acceleration/deceleration time
1: Acceleration/Deceleration time 1
2: Acceleration/Deceleration time 2
3: Acceleration/Deceleration time 3
4: Acceleration/Deceleration time 4
- 0
Im St
S
Group H17: VDI/VDO Parameters
Function
Code
Parameter Name Setting Range Unit Default
ET Pro
CM
H17-00 VDI1 function selection 0 to 37 - 0
St Ru
-
H17-01 VDI1 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-02 VDI2 function selection 0 to 37 - 0
St Ru
-
H17-03 VDI2 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-04 VDI3 function selection 0 to 37 - 0
St Ru
-
H17-05 VDI3 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-06 VDI4 function selection 0 to 37 - 0
St Ru
-
H17-07 VDI4 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-08 VDI5 function selection 0 to 37 - 0
St Ru
-
H17-09 VDI5 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-10 VDI6 function selection 0 to 37 - 0
St Ru
-
H17-11 VDI6 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-12 VDI7 function selection 0 to 37 - 0
St Ru
-
H17-13 VDI7 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-14 VDI8 function selection 0 to 37 - 0
St Ru
-
H17-15 VDI8 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-16 VDI9 function selection 0 to 37 - 0
St Ru
-
H17-17 VDI9 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-18 VDI10 function selection 0 to 37 - 0
St Ru
-
H17-19 VDI10 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-20 VDI11 function selection 0 to 37 - 0
St Ru
-
H17-21 VDI11 logic selection
0: Valid when logic is 1
1: Valid when logic changes from 0 to 1
- 0
St Ru
-
H17-22 VDI12 function selection 0 to 37 - 0
St Ru
-
