Technical Specification
2. Resistance programming accuracy differs based on different output current.
For example, 10A Transient 1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A)
= 40mΩ.1.0Ω, accuracy: (1.0Ω * 0.25%) +(375mΩ*A /10A) = 40mΩ.
3. Set value accuracy means the set accuracy realized through the panel button
or communication instructions. When external analog is used for programming,
the programming accuracy is 2%FS.
4. Read-back value accuracy means the read-back accuracy realized through
panel display or communication instructions; when external analog is used for
monitoring, the monitoring accuracy is 1%FS.
5. Up time and down time mean the time of establishment from one value to
another value under ON status when the internal standard power dissipater is
enabled.
6. Use 12V/120AH battery for test.
7. When used in parallel, to balance power of each phase, distribute the
instrument to three phases. But must ensure that single machine input voltage
meets Specification requirements.
8. It means the maximum phase current value under minimum work input
voltage.
5.1.10 IT6515C
Parameter IT6515C Ver:V1.6
Output Rating ( 0 ℃-40
℃)
Output Voltage
0～500V
Output Current
0～20A
Internal Sink Current
1
0～8A
Output Power
0～1800W
Internal Sink Power
1
0～150W
Output Resistance
Range
0～138.88Ω
Accuracy
2
0.25%+200mΩ
Resolution 10mΩ
Line regulation
±(％of Output+Offset)
Voltage
≤0.01%+50mV
Current ≤0.01%+10mA
Load regulation
±(％of Output+Offset)
Voltage
≤0.01%+100mV
Current ≤0.05%+20mA
Setup Resolution
Voltage
100mV
Current 10mA
