8.2 Setting the truck parameters with CanCode
CAUTION!
Faulty entry
Without CanDis only CanCode internal parameters can be changed. Traction
controller parameters can only be changed with CanDis, without CanDis the settings
must be performed by the manufacturer's service department.
CAUTION!
Altering settings for the travel, steering and hydraulic functions can result in
accidents
Increasing or decreasing the settings for travel, steering and hydraulic functions can
result in accidents.
u
Carry out a test run in a secure environment.
u
This requires greater attention on the part of the operator.
Parameter setting example
The following example shows the parameter setting for the acceleration of travel
program 1 (parameter 0256).
Acceleration example
Procedure
• Enter four-digit parameter number "0256" and confirm with the SET key (75).
• Enter sub-index (enter "2") and confirm with the SET key (75).
Z
The parameter and sub index are displayed alternately with the current reading
(0256-2<->0000-3).
• Enter the parameter according to the parameter list and confirm with the Set key
(75).
Z
The LED (76) of the O key (77) switches briefly to steady light and start flashing
again after approx. 2 seconds.
Z
If the entry is incorrect, the LED (76) of the O key (77) turns red. Enter the
parameter number again to repeat the setting.
Z
The parameter and sub index are displayed alternately with the entry (0256-2<-
>0000-5).
The travel parameter is now set.
Repeat the procedure to enter further parameters as soon as the LED (76) of the O
key (77) flashes.
Z
Travel is disabled while the parameters are being entered.
Checking the settings in programming mode
Procedure
• Select the travel program to be worked on after changing the parameter value,
and confirm with the Set key (75).
132
04.19 en-GB
